Edge AI hardware runs compute-heavy workloads in places with no data-center cooling: factory floors, roadside cabinets, robots, vehicles. When heat is not managed, the processor throttles and your model runs slower than in the lab, components age faster, and enclosures become too hot to touch. Thermal design is an enclosure decision as much as an electronics one.
Follow the heat path
- Source — SoC, GPU/NPU, power regulators, memory.
- Thermal interface material (TIM) — pad, paste or phase-change material that fills the gap between chip and metal.
- Spreader / heat sink — a copper or aluminum block, heat pipe or vapor chamber.
- Enclosure — in fanless designs, the enclosure itself is the heat sink.
- Ambient — air around the device, by natural convection, forced airflow or radiation.
The weakest link sets the temperature. A good heat sink is wasted if the TIM layer is too thick or the chip does not contact it evenly.
Fanless or active cooling?
| Approach | Pros | Cons |
|---|---|---|
| Fanless (enclosure as heat sink) | No moving parts, can be sealed against dust and water, silent | Larger and heavier for the same power; limited by surface area |
| Active (fan) | Much more heat removed in a small volume | Dust, filters, noise, fan wear; harder to seal |
| Hybrid | Fanless at normal load, fan for peaks | More complex control and testing |
Enclosure design details that matter
- Material: aluminum conducts heat well and is easy to machine or extrude into fins (see choosing metals).
- Fins: for natural convection, orient fins vertically in the installed position and keep enough spacing for air to flow; denser fins are not always better.
- Surface finish: dark anodized or coated surfaces radiate heat better than bare polished aluminum.
- TIM tolerance: design the gap between chip and heat sink with the stack-up of PCB, standoffs and machining tolerances in mind.
- Hot spots: keep power regulators and memory in the thermal path too, not just the main processor.
- Touch temperature: product safety standards (for example IEC 62368-1 for ICT equipment) limit accessible surface temperatures — check them for your product category.
Test at worst case, not on the desk
- Define maximum ambient temperature and installation (enclosed cabinet, direct sun, mounting orientation).
- Run the real worst-case workload, not an idle benchmark.
- Log chip temperature, throttling events and surface temperatures in a thermal chamber.
- Repeat with production enclosures and TIM — prototypes in other materials behave differently.
